Scanner Type
|
ADF (Automatic Document Feeder) / Manual Feed, Duplex
|
|
ADF
|
Simplex: 40 ppm (200/300 dpi)
Duplex: 80 ipm (200/300 dpi)
|
|
Manual Feed
|
3.5 seconds (200/300 dpi)
|
|
Image Sensor Type
|
CIS x 2 (front x 1, back x 1)
|
|
Light Source
|
RGB LED (front x 1, back x 1)
|
|
Optical Resolution
|
600 dpi
|
|
Output Resolution (4)
(Color / Grayscale / Monochrome)
|
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5)
|
|
Output Format
|
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
|
|
Background Colors
|
White
|
|
Document Size
|
Maximum 215.9 x 355.6 mm (8.5 x 14 in.)
Minimum 50.8 x 50.8 mm (2 x 2 in.)
Long Page Scanning (6) 5,588 mm (220 in.)
|
|
Paper Weight (Thickness)
|
ADF Paper: 40 to 127 g/m² (11 to 34 lb)
For A6 or smaller: 40 to 209 g/m² (11 to 56 lb)
For A8 or smaller: 127 to 209 g/m² (34 to 56 lb)
Manual Feed Paper: 20 to 413 g/m² (5.4 to 110 lb)
Plastic card: 1.4mm or less
Booklet: 5mm or less
|
|
ADF Capacity
|
20 sheets (A4 80 g/m² or Letter 20 lb)
30 sheets (A4 52 g/m² or Letter 14 lb)
|
|
Expected Daily Volume
|
4,500 sheets
|
|
Multifeed Detection
|
Overlap detection (Ultrasonic sensor)
|
|
Interface
|
USB 3.2 Gen1x1 / USB 2.0 / USB 1.1
|
|
Power Requirements
|
AC 100 to 240 V 10 %
|
|
Power Consumption
|
Operating Mode 19 W or less
Sleep Mode 1.7 W or less
Auto Standby (Off) Mode 0.15 W or less
|
|
Operating Environment
|
Temperature 5 to 35 C (41 to 95 F)
Relative Humidity 20 to 80% (Non-condensing)
|
|
Environmental Compliance
|
ENERGY STAR, RoHS
|
|
Dimensions (W x D x H)
|
296 x 105 x 83 mm (11.7 x 4.1 x 3.3 in.)
|
|
Weight
|
2.0 kg (4.4 lb)
|
|
Supported Operating System
|
Windows 10 (10), Windows 8.1, Windows 7, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008
|
|
Included Software / Drivers
|
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver (12), PaperStream Capture, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™ (13), Scanner Central Admin
|
|
Image Processing Functions
|
Multi image output, Automatic color detection, Blank page detection, Static threshold, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Cropping, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Character extraction, Background pattern removal
|
|
Included Items
|
AC cable, AC adapter, USB cable, Setup DVD-ROM
|
|
