מעבד
|
AnnapurnaLabs Alpine AL-324 ARM® Cortex-A57 quad-core 1.7GHz processor
|
|
CPU Architecture
|
64-bit x86
|
|
Floating Point Unit
|
YES
|
|
Encryption Engine
|
YES
|
|
System Memory
|
2 GB SODIMM DDR4(1 x 2 GB)
|
|
Maximum Memory
|
16 GB (1 x 16 GB)
|
|
Memory Slot
|
1 x SO-DIMM DDR4
|
|
Flash Memory
|
512 MB (Dual boot OS protection)
|
|
Drive Bay
|
8 x 3.5-inch SATA 6Gb/s, 3Gb/s
|
|
Drive Compatibility
|
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
|
|
Hot-swappable
|
YES
|
|
M.2 SSD Slot
|
Optional via a PCIe adapter
|
|
SSD Cache Acceleration Support
|
YES
|
|
Gigabit Ethernet Port (RJ45)
|
2
|
|
10 Gigabit Ethernet Port
|
2 x 10GbE SFP+
|
|
Jumbo Frame
|
YES
|
|
PCIe Slot
|
2
Slot 1: PCIe Gen 2 x1
Slot 2: PCIe Gen 2 x2
PCIe bandwidth limitations will restrict the NAS 10GbE performance.
|
|
USB 3.2 Gen 1 port
|
3
|
|
Audio Output
|
1 x built-in speaker, 1 x 3.5mm line out jack (for amplifiers or speakers)
You cannot use the speakers and the line-out jack simultaneously.
|
|
Form Factor
|
Tower
|
|
LED Indicators
|
System Status, LAN, USB, HDD1~8
|
|
Buttons
|
Power, Reset, USB Copy
|
|
Dimensions (HxWxD)
|
188.2 X 329.3 X 279.6 mm
|
|
Weight (Net)
|
6.38 kg
|
|
Weight (Gross)
|
8.61 kg
|
|
Operating temperature
|
0-40C
|
|
Relative Humidity
|
5-95 %
|
|
Power Supply Unit
|
250W, 100-240V AC, 50/60Hz, 3.5A
|
|
Power Consumption: HDD Sleep Mode
|
24.53 W
|
|
Power Consumption: Operating Mode, Typical
|
49.43 W
With drives fully populated
|
|
Fan
|
System fan: 2 x 120mm, 12VDC
CPU fan: 1 x 60mm
|
|
Sound Level
|
20.7 db(A)
|
|
System Warning
|
Voice prompts or Buzzer
|
|
Kensington Security Slot
|
YES
|
|
Max. Number of Concurrent Connections (CIFS)
|
1500
|
|
